Druck Ex-Proof Digital Pressure Gauge | DPI 104-IS

The DPI 104-IS is an intrinsically safe version of the microprocessor-controlled DPI 104-digital pressure gauge. The DPI 104-IS matches advanced silicon sensor technology with several convenient design features, resulting in an accurate, versatile yet affordable digital test gauge. Supplied as a stand- alone process indicator or in a kit with the widely proven Druck hand pumps, the DPI 104-IS provides a reliable and economic solution for a wide range of pressure sensing applications.

The DPI 104-IS is an intrinsically safe version of the microprocessor-controlled DPI 104-digital pressure gauge.

The DPI 104-IS matches advanced silicon sensor technology with several convenient design features, resulting in an accurate, versatile yet affordable digital test gauge. Supplied as a stand- alone process indicator or in a kit with the widely proven Druck hand pumps, the DPI 104-IS provides a reliable and economic solution for a wide range of pressure sensing applications.

Loading...

Features and Benefits

  • Intrinsically safe
  • ATEX, IECEx, cETL (Canada)
  • 0.05% full scale (FS) accuracy
  • Pressure ranges to 20,000 psi (1400 bar)
  • Eleven selectable pressure units
  • Large, easy-to-read display with five-digit resolution
  • Free of charge monitoring and control software
  • % pressure indication and additional bar graph for quick visual reference
  • Temperature compensated accuracy from 14°F to 122°F (-10°C to 50°C)
  • Pressure switch test
  • Minimum/maximum, tare and alarm function
  • Stainless steel or Inconel pressure cavity for aggressive media
